Demister pads are a type of mesh pad used for removing water and oil droplets suspended in air or other gases. They offer an efficient solution for efficiently trapping, separating, or coalescing gas or liquid particles from process streams. The material selected depends on the application.

Wire mesh demisters are utilized for separating liquids and vapours in petrochemical, oil and gas processing, waste treatment, power generation, and pharmaceutical process plants, among other industries. They are made from woven or knitted wire mesh and serve as coalescing filters to separate not only liquid and gas mixtures, but also solid-liquid and solid-gas mixtures.

Major materials are as per the below:
1. SUS304, 304L, SUS316, 316L, MONEL，Copper and Galvanized materials.
2. P.P (POLY PROPYLENE), P.E (POLY ETHYLENE), TEFLON
3.GLASS FIBER

The length and width of the mesh can vary and are determined by the size of the vessel, the type of application, and the desired pressure drop.

The surface treatment of the wire mesh demister depends on the application, with some treated with corrosion inhibitors, solvents, or oils. Installation of the demister can be done either directly in the vessel or externally using frames or baskets.

The main differences between stainless steel, monel, copper, and galvanized wire mesh demisters are their mechanical strength, corrosion resistance, weight, and cost.

Stainless steel is the most common material used for demisters due to its high durability and resistance to corrosion. Monel is also highly corrosion resistant and is able to withstand extreme temperatures and pressures. Copper is lighter and more conductive than both stainless and Monel, making it ideal for electrical applications. Galvanized materials are much cheaper than the other three and offer good corrosion resistance, however they lack the same level of strength and durability.

Features of Wire Mesh Demister:
1. Simple structure with light weight.
2. Less pressure drop and big surface.
3. High demisting efficiency.
4. It is convenient for installation, operation and maintenance.
5. Long service life.

The following is an example of ten names and descriptions of Mesh Pad Type Demisters:

1. Stainless steel mesh type pad demister: This is a wire mesh pad demister made from stainless steel wire mesh for use in large-scale liquid and vapor separation systems.
2. Polyester mesh pad demister: This is a woven polyester mesh pad demister, often used in scrubbers and other vapor-liquid separator units.
3. Stainless steel tube pad demister: This is a cylindrical demister made from stainless steel, commonly used in gas turbine inlet systems.
4. Aluminum honeycomb pad demister: This is a lightweight, aluminum honeycomb pad demister that provides highly efficient removal of liquids and vapors.
5. Monel mesh pad demister: This is a corrosion-resistant monel mesh pad demister, ideal for high temperature applications.
6. Bronze mesh pad demister: This is a bronze mesh pad demister, designed for use in evacuation systems.
7. Glass-fiber mesh pad demister: This is a glass-fiber mesh pad demister, intended for use in small tanks, coolers and separators.
8. Nickel-alloy mesh pad demister: This is a nickel-alloy mesh pad demister, suitable for corrosive environments.
9. Titanium wire mesh pad demister: This is a titanium wire mesh pad demister, designed for higher temperature applications.
10. Polypropylene mesh pad demister: This is a lightweight, low-cost polypropylene mesh pad demister, commonly used in gas turbine inlet systems.

Yingdu supply of demister wire mesh pads, various types

For example

Demister Wire Mesh Pads
Pad:Demister, 15 in wd X 48 In lg X 6 in Thk,Ss Aisi-347
Item Specifications :
Type : Demister Pad, Wire Mesh
Demister, No Mod
Dimensions : Wire Dia 0.25 Mm X 300 M2 Surfacearea
Material : SS AISI-347
Style: York 431 Or Knit Mesh Type 9030 Or Equivalent
Material : AISI - 347 SS
Free Volume : 98%
Density : 145 Kg/M3
Surface Area: 300 M2
Wire Dia : 0.25 mm
Width Inches :15"
Length Inches: 48"
Thickness Inches: 6"
(Made In One Piece With Tie Wires For Securing To The Support Rings.)
